Electrodes for Spark Plug Applications

Increasingly high quality materials and components are being used in order to meet the growing requirements for combustion engines with respect to fuel efficiency and emissions.

About Electrodes for Spark Plugs

High-quality materials based on precious metals are increasingly utilized for spark plug electrodes. These materials offer thermal stability and long service life due to their resistance to wear and oxidation. We customize the mechanical properties to meet your specific requirements for optimal processing and workability. ​

Greater efficiency in fuel combustion and reduced CO2 emissions lead to compliance with future environmental standards. Our electrode materials for center and ground electrodes in spark plug applications are manufactured from high-quality alloys of the platinum group metals, enabling spark plugs to outlast conventional variants with non-precious electrodes by a significantly greater margin.​

Share your individual applications and specifications with us. Our experts will be happy to advise you.

Get Advice on Your Specific Requirements

Material Database

Find the right material for your product in our material database.

Advantages

  • Long service life and reliability due to wear- and oxidation-resistant materials
  • Optimal ignition of the fuel mixture
  • Good workability
  • Material properties adapted to your applications
  • Cost savings from reduced precious metal content
  • Maintains narrow manufacturing tolerances
  • Fine grain stabilized materials (DPH)
  • Customized formed and composite parts

Product Properties & Technical Data

Our spark plug electrodes are available in the form of continuous and cut wires, rivets, balls, discs, and crosses.

  • Wire diameter for spark plug electrodes ≥ 0.20 mm
  • Sheet thickness ≥ 0.15 mm
  • Ball diameter ≥ 0.2 mm
  • Pt alloys, e.g. PtNi, PtRh, PtIr, PtPd
  • Fine grain stabilized materials (DPH)
  • Ir alloys, e.g. IrRh, IrRe, IrRhRe
